| Type |
Center Frequency |
Bandwidth at 6dB |
Carrier Frequency (SSB Use) |
Bandwidth at 60dB Attenuation |
Gain
per Stage (Gm=4m/Ω) Transmission Loss |
Input
Terminal Resistance |
Input
Terminal Capacitance |
Output
Terminal Resistance |
Output
Terminal Capacitance |
Size (mm) |
Loss (dB) |
Note |
| MF 455-05CK |
455kHz |
1kHz |
within 5.5kHz |
35φ x 65 h |
20 |
CW valve use |
||||||
| MF 455-10CK | 455kHz | 2kHz | within 6kHz | 35φ x 65 h |
SSB valve use |
|||||||
| MF 455-15CK | 455kHz | 3kHz | within 9kHz | 35φ x 65 h |
AM valve use |
|||||||
| MF 455-10Z 27 | 455kHz | 2kHz | 456.5kHz 453.5kHz |
within 6kHz | 3dB | 10kΩ |
10kΩ | 45x15x15 (wxhxd) |
10 or less |
SSB valve use |
||
| MF 455-10Z 28 | 455kHz | 2kHz | within 6kHz | 10kΩ | 1kΩ | 45x15x15 (wxhxd) |
SSB TR. use |
|
|
|
