Lafayette Antenna Impedance Meter 99-33094 (ラファイエット アンテナインピーダンスメータ) Updated 2001/03/24,04/18

  • 2000/12/22    入手、取説を見るとデリカ（三田無線）のディップメータ(Dip Meter)を信号源に使った写真があるが三田無線のOEMでは無いようだ。

    • Specifications (仕様概要）
    Main unit
    Items
    Specifications
    Measurable Range of Impedance 10 - 500 ohms
    Frequency Range 3 - 150 MHz
    Calibration Circuit Built-in 50 ohm resister
    Meter + - 50uA, "0" center
    Battery 9 volt (006P)
    Dimentions 7 1/2"L x 3"W x 4"H
    Net Weight 1 3/4 lbs.

    Plug-in Oscillator
    Items Specifications
    Frequency 27.125 MHz
    Connectors [crystal-controlled]
    [3] Plug-in to main
    impedance meter
    Dimentions 3 3/4"L x 2"W x 1 9/16"H
    Net Weight 5 1/4 oz.
